Fɛn minnu bɛ dilan, olu ɲɛfɔli .

Sisi dɔgɔya halojeni-Kɔrɔnfura fu-Poliɛtilɛni jɛlen insulasi kuran kabɔriw .bɛ bɛn so kɔnɔ ani kɛnɛma fixe installation ma low-voltage power systems kɔnɔ. Misali la, kuran fanga tilatilali dugubaw kɔnɔ, kuran walima fɛn caman sɛgɛsɛgɛlikɛyɔrɔw la, ani iziniw kɔnɔ.

Conducteur .

Class 2 ordinaire annealed stranded circular or circular compacted oxygène free copper conducteur ka kɛɲɛ ni IEC 60228. walima IEC 5 of IEC 60228 (RV-K suguya) ye.

Insulation .

Cross linked poliyetilɛni (XLPE) bɛ bɔ kɛnɛ kan ka kɛɲɛ ni IEC 60502-1 ye.

Kɛnɛma-sɔgɔli .

Polivinili kuloridi (PVC) Layɛrɛ min bɛ bɔ kɛnɛ kan – ST2 suguya ka kɛɲɛ ni IEC 60502-1 ye.

Cross-Polyilɛni fanga kabɔriw minnu bɛ ɲɔgɔn kan .

Produits paramètre .

Standards for Mica Tape No Halogen XLPE insulated power cable in 0.6/1KV LV .

0.6KV/ 1KV PVC insulated (tasuma- resistant) fanga kabɔri bɛ bɛn GB/T 12706-2008 jamana sariya ma min bɛ bɛn IEC 60502-2004 ma.

Tasuma-fanga-minɛn bɛ bɛn GB/T 18380-2008 ma min kɔrɔ ye ko a fana bɛ IEC 60332-2004 wasa.

No.of cores×section . (mm2) .	Insulation normale . thickness(mm) .	Normal thickness ka . Overshath .		A bɛɛ lajɛlen bɛ bɛn . Diamètre de cable(mm) .		Kisɛ hakɛ jateminɛlen . kabɔri(kg/km) .
		Normal thickness ka . Overshath .		A bɛɛ lajɛlen bɛ bɛn . Diamètre de cable(mm) .		Cu .		Al .
		Marifa tɛ min na .	Armoured .	Marifa tɛ min na .	Armoured .	YJV ye .	YJV22 .	YJLV ye .	YJLV22 ye.
4×4	0.7	1.8	1.8	12.5	18.1	282	430	/	/
4×6	0.7	1.8	1.8	14.7	17	383	545	/	/
4×10	0.7	1.8	1.8	16.9	19.1	565	752	390	517
4×16	0.7	1.8	1.8	19.3	21.6	783	1020	416	663
4×25	0.9	1.8	1.8	23.5	25.7	1241	1502	593	902
4×35	0.9	1.8	1.8	26.7	28.7	1631	1957	776	1096
4×50	1.0	1.8	1.9	28.0	32.6	2080	2812	961	1770
4×70	1.1	2.0	2.1	33.2	37.5	2952	3796	1302	2222
4×95	1.1	2.1	2.3	38.0	42.6	3970	4962	1693	2757
4×120	1.2	2.3	2.4	40.9	46.4	4894	5913	2077	3363
4×150	1.4	2.4	2.6	46.0	51.3	5980	7170	2852	3878
4×185	1.6	2.6	2.7	52.5	57.8	7442	8802	3173	4618
4×240	1.7	2.8	3.0	59.4	64.6	9764	11289	4032	5782
4×300	1.8	3.0	3.1	66.2	71.6	12122	13856	4924	6735
4×400	2.0	3.3	3.4	73.8	80.3	15624	18407	6272	9313
4×500	2.2	3.5	3.7	89.3	96	19877	23264	7667	11062
4×630	2.4	3.8	4.0	99.6	106.3	25124	28895	9514	13293

Fɛn minnu bɛ kɛ ka aw yɛrɛ tanga .

Sisi dɔgɔman Halogen XLPE insulated power cable installation fɛɛrɛw:

1. Ni aw bɛ kabali da, o hakɛ fitinin tɛ dɔgɔya ka bɔ kabali kɛnɛma janya la siɲɛ 10.

2. YJV / YJLV kabɔliw bɛ bila so kɔnɔ, kanw ni pipew kɔnɔ, wa u bɛ se ka su fana dugukolo lafiyalen na, min tɛ se ka kɛnɛma fanga muɲu.

3. YJV22 / YJLV22 kabɔriw bɛ bila dugujukɔrɔ ani u bɛ se ka kɛnɛma masina fanga muɲu, nka u tɛ se ka fanga belebelew muɲu.

4. Baarakɛminɛn kɛrɛnkɛrɛnnenw ka kan ka kɛ kabɛl labɔli la, i n’a fɔ sara-off racks, guide rollers, ani fɛn wɛrɛw, walasa ka masinw tiɲɛni bali dabila waati la ani ka u yɔrɔ janya funteni sɔrɔyɔrɔw la.

5. Ni aw bɛ kabali da pipe fɛ, pipe kɔnɔna janya man kan ka dɔgɔya ni digi kɛnɛma janya ye siɲɛ 1,5.

A ka kan ka bidden ka kabali sɔgɔ ni a tɛmɛna pipe fɛ. Kabali yɔrɔ bɛɛ man kan ka tɛmɛ 40% kan pipe yɔrɔ bɛɛ la.

Fɛn minnu bɛ kɛ ka fɛnw kɛ .

A kɛcogo ɲumanw sisi dɔgɔman na No Halogen XLPE insulated power cable in 0.6/1KV LV .
1. Voltage U0/U: 0,6/1KV .
2. A bɛ se ka kɛ waati jan-waati baara funteni hakɛ: 70℃.
3. Kurukuru: Kunnafonidila funteni ka dɔgɔn walima a bɛ bɛn degere 160 ma , a bɛ mɛn ka tɛmɛ walima a bɛ bɛn segin 5 ma .
4. Lamini funteni ka kan ka tɛmɛ degere 0 kan ni a bɛ da, wa a ka kan ka sumaya ni funteni bɛ degere 0 duguma . Layidu tacogo tɛ nɔ bila jiginɛ janya la.
5. Minimum bending radius laying waati la: 20 siɲɛ 20 kabɔri cɛmancɛ la core suguya kelen na, ani siɲɛ 15 multi-core suguya la.
6. Five{.
